12.19″ Wilwood Forged Dynalite Pro Series Rear Brake Kit 140-3018-BD

$877.77

Forged Dynalite Pro Series Rear Brake Kit

FDL Pro-Series rear disc brake kits provide a complete solution for popular muscle car rear axles on applications where individual wheel parking brake assemblies are not required. Forged billet Dynalite four piston calipers, two-piece hat and rotor assemblies, and high friction pads provide optimized and balanced braking for all types of off-road, competition, and other customized applications. FDL calipers can be optioned with a full range of finishes to reflect personalized style. Rotor choices provide options for high-tech show winning style, or heavy weight durability and cooling capacity for high heat competition.



Compatible Vehicles for this Brake Kit
BRAKE KIT:   Forged Dynalite Pro Series Rear Brake KitThis Brake Kit is Compatible with the Following Vehicle Makes:   Ford Mercury

Note: Kit may fit other vehicles, call Wilwood Sales⁄Tech Support at (805) 388-1188 for more information.

REAR END:   8.8 Ford – Rear KitAXLE OFFSET:   2.50

For a Complete Listing including ALL Makes, Models and Years, Please click on the Axle Offset.

fitment 1
Rear End / Axle Housing Flange
Confirm The Configuration!

8.8 Ford Flange
Confirm Offset Measurement!

AXLE FLANGE CROSS-SECTION
Search Rear Kits By Rear End/Axle Offset



caution AXLE OFFSET: 2.50
Check the diagram above and verify this measurement. This kit may be available in several different offsets.
Please call Wilwood with any questions: (805) 388-1188

SKU: RC-WWBK-140-3018-BD Category: Tag:

Description

Kit Summary
Rear End Axle: 8.8 Ford
Axle Offset: 2.50
Mount Type: Lug
Caliper Type: 4 – Black Powder Coat
Rotor Diameter: 12.19
Min Wheel Diameter Req’d*: 15
*This Brake Kit may fit 15-inch wheels. Please refer to the wheel clearance diagram to check to see if it will fit your specific wheel. Wheel Clearance Diagram
UPC Number
UPC 889545022353
WARNING: Cancer and Reproductive Harm
www.P65Warnings.ca.gov
Applicable to Brake Pads Only







Kit Components & Specifications
Calipers
Left Hand – Part No: 120-13839-BK
Right Hand – Part No: 120-13839-BK
Type: Forged Dynalite Internal
Finish Color: Black Powder Coat
Piston Count: 4
Piston 1 Bore (in): 1.38
Piston 2 Bore (in): 1.38
Piston Area (In²): 3.00
Piston Type: Stainless
Mount Type: Lug
Brake Pad Plate: 7112
Brake Pad Area (In²): 6.36
Brake Pad Volume (In³): 2.1
Pad Compound: BP-10
Rotors
Left Hand – Part No: 160-7106-BK
Right Hand – Part No: 160-7105-BK
Type: SRP Drilled Rotor
Style: SRP Drilled & Slotted
Surface Finish: Black Electro Coat
Material: Iron
Outside Diameter (in): 12.19
Width (in): 0.81
Vane Count: 32 V
Design Type: SRP-BLK
Bedded: No
Dynamically Balanced: No
Rotor Hats
Hat – Part No: 170-1827
Type: Pro-Street Hat – Standard
Material: Aluminum
Finish Color: Black E-Coat
Hat Offset Dimension (in): 2.000
Bolt Circle 1: 5 X 4.50
Bolt Circle 2: 5 X 4.75
Bolt Circle 3: 5 X 5.00
Stud Diameter – BC 1: 0.520
Stud Diameter – BC 2: 0.520
Stud Diameter – BC 3: 0.520
Hubs
Hub – Part No:
Type:
Material:
Finish Color:
Mount Style:
Bolt Circle 1:
Bolt Circle 2:
Bolt Circle 3:
Stud Diameter – BC 1:
Stud Diameter – BC 2:
Stud Diameter – BC 3:



Parts & Accessories
Caliper Parts
O-ring Kit: 130-2658
Replacement Dustboot: N-A
Replacement Piston 1: 200-7518
Replacement Piston 2: 200-7518
Replacement Piston 3: N-A
Replacement Piston 4: N-A
CrossOver O-Ring Kit: 130-10540
Crossover Tube: N-A
Self-Bleeder Tube: N-A
Bridge Bolt Kit: N-A
Wear Plate – Left Hand: 300-5875
Wear Plate – Right Hand: 300-5875
Pad Retainer: 180-0055
Bleed Screw Kit: 220-0627
Brake Lines
Hat
Bolt Kit: 230-0150
Hub
Bolt Kit:

Additional information

Weight 50 lbs
Dimensions 14 × 14 × 17 in
